chm-751 specifications | |
dimensions | 1280mm(l)×1190mm(w)×1470mm(h) |
weight | 540kg |
power supply | ac220v (50hz, single phase), 2.8kw |
air supply | 0.5mpa ~0.7mpa |
vacuum generation | vacuum pump |
mounting head quantity | 6 |
mounting speed | 18400cph (optimal) |
mounting accuracy | (xy)±0.05mm cpk≥1.0 |
control accuracy | 5μm |
component height | 12mm |
component type | 0201/0402/0603~5050/sot/sop/qfp/qfn/bga, etc. (resistor/capacitor/diode/triode/led/ic, etc.) |
pcb thickness | 0.6mm~3.5mm |
pcb size | 400mm(l)×350mm(w) |
pcb conveying | 3-section-rail automatic conveying; pcb supporting device |
nozzle change | automatic nozzle change (19-hole nozzle library) |
control system | built-in industrial computer board equipped with monitor, keyboard, and mouse |
drive system | x&y axis driven by servo motors (y axis by double motors); adopting flexible s-curve acceleration and deceleration |
transmission system | ground screw rod linear guide (y axis using double screw rods double linear guides) |
feeding system | 50 yamaha 8mm standard pneumatic/electric feeder stacks (also suitable for ic tray and stick feeder) |
vision system | snapshot camera×6 (component size applicable: 16mm×16mm); ic camera×1 (component size applicable: 36mm×36mm); mark camera×2 |
